Fence Brackets
fence brackets
Provides a secure fit for the connection of 2 x 4 fence boards to post.
Quick Actions:
Provides a secure fit for the connection of 2 x 4 fence boards to post. Easier to plan and build, holes are sized to #6 wood screws or 8d nails.
Material: 20ga (33mil), 0.0346" Design thickness, 0.0329" Minimum thickness
Coating: G185 (Z550) Hot-dipped galvanized coating
Yield Strength: Structural Grade 50 Type H (ST50H), 50ksi (340 MPa)
- Clip Express Sales at 866-638-1908 or clipexpress@clarkdietrich.com
- Technical Support at 888-437-3244 or support@clarkdietrich.com
| Product Code | Gauge | Depth | Width | Height |
|---|---|---|---|---|
| CDFB24G | 20 | 3/4" | 1-5/8" | 3-3/8" |
